Dell UltraSharp 34 Curved Thunderbolt™ Hub Monitor - U3425WE

FEATURE TECHNICAL SPECIFICATION MODEL Dell UltraSharp 34 Curved Thunderbolt™ Hub Monitor - U3425WE DIAGONAL VIEWING SIZE 867.16 mm (34.14 inches) PRESET DISPLAY AREA (H X V) 799.80 mm x 334.80 mm (31.49 inches x 13.18 inches) PANEL TYPE IPS Black Technology DISPLAY SCREEN COATING Anti-Glare with 3H hardness MAXIMUM PRESET RESOLUTION 3440 x 1440 at 120 Hz VIEWING ANGLE 178° vertical / 178° horizontal PIXEL PITCH 0.2325 mm x 0.2325 mm PIXEL PER INCH (PPI) 110 CONTRAST RATIO 2000 to 1 (typical) CURVATURE 1900R ASPECT RATIO 21:9 BACKLIGHT TECHNOLOGY LED Edgelight System BRIGHTNESS 300 cd/m2 (typical) RESPONSE TIME 8 ms (Normal) 5 ms (Fast) HDR No AMBIENT LIGHT SENSOR Yes, auto brightness and color temperature adjustmemt TÜV EYE COMFORT CERTIFICATION 5 Stars CONNECTIVITY •1 x HDMI port (HDCP1.4 & 2.2) (supports up to WQHD 3440 x 1440 100 Hz TMDS as per specified in HDMI 2.1) •1 x DP 1.4 (HDCP1.4 & 2.2) (supports up to WQHD 3440 x 1440 120 Hz) •1 x Thunderbolt™ 4 downstream port (15W) for daisy chaining (Video + Data) •1 x Thunderbolt™ 4 upstream port (Video + Data). Alternate mode with DisplayPort 1.4, Power Delivery up to 90W •1 x USB-Type C upstream port (data only) (super speed USB 10Gbps, USB 3.2 Gen2) •4 x USB Type-A downstream port (super speed USB 10Gbps, USB 3.2 Gen2) •1 x Audio line-out port •1 x RJ45 Ethernet port, 2.5GbE Quick Access: •1 x USB Type-A downstream port (super speed USB 10Gbps, USB 3.2 Gen2) with BC1.2 power charging • 2 x USB Type-C downstream port (super speed USB 10Gbps, USB 3.2 Gen2) with power charging (15W) ADJUSTABILITY Height adjustable (150 mm) Tilt (-5° to 21°) Swivel (-30° to 30°) PBP / PIP Yes KEYBOARD, VIDEO AND MOUSE (KVM) Yes DAISY CHAIN AVAILABILITY Yes AUDIO OUTPUT 1 x Audio line-out1 BUILT-IN SPEAKER 2 x 5 W DELL DISPLAY MANAGER COMPATIBILITY Yes, Easy Arrange, Other key features FEATURE TECHNICAL SPECIFICATION SPECIFICATIONS - SERVICE / SUPPORT DETAILS 3-Year Advanced Exchange Service and Premium Panel Exchange COLOR GAMUT •DCI-P3 98% •Display P3 98% • sRGB 100% •1.07 Billion colors (8bit + A-FRC) •DCI-P3, Display P3, sRGB & BT.709: Delta E < 2 (average) HEIGHT WITH STAND (COMPRESSED ~ EXTENDED) 392.83 mm ~ 542.83 mm (15.47” ~ 21.37”) WIDTH WITH STAND 813.46 mm (32.03”) DEPTH WITH STAND 240.43 mm (9.47”) HEIGHT WITHOUT STAND 359.15 mm (14.14”) WIDTH WITHOUT STAND 813.46 mm (32.03”) DEPTH WITHOUT STAND 105.08 mm (4.14”) WEIGHT (PANEL ONLY - FOR VESA MOUNT) 7.78 kg (17.15 lb) WEIGHT (WITH STAND ASSEMBLY AND CABLES) 10.81 kg (23.83 lb) WEIGHT (WITH PACKAGING) 15.05 kg (33.17 lb) SECURITY Security lock slot (cable lock sold separately) Anti-theft stand lock slot (to lock stand to monitor using screw) COMPLIANT STANDARDS •ENERGY STAR® certified monitor •EPEAT® registered where applicable. EPEAT registration varies by country. See www.epeat.net for registration status by country. •RoHS-compliant •TCO Certified & TCO Certified Edge • BFR/PVC free monitor (excluding external cables) •Arsenic-free glass and Mercury-free for the panel only FLAT PANEL MOUNT INTERFACE VESA mounting holes (100 mm x 100 mm - behind attached VESA Cover) TEMPERATURE RANGE Operating: 0°C to 40°C (32°F to 104°F) Non-operating: -20°C to 60°C (-4°F to 140°F) - Storage and Shipping HUMIDITY RANGE Operating: 10% to 80% (non-condensing) Non-Operating: 5% to 90% (non-condensing) - Storage and Shipping ALTITUDE Operating: 5000 m (16404 ft) max Non-Operating: 12192 (40000 ft) max VOLTAGE REQUIRED 100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 3.2 A (typical) POWER CONSUMPTION NORMAL OPERATION 0.3 W (Off mode)2 0.5 W (Standby mode)2 1.9 W (Networked Standby mode)2 31.5 W (On mode)2 250 W (Max.)3 29.3 W (Pon)4 99 kWh (TEC)4 WHAT’S INCLUDED Monitor, Stand Riser, Stand Base 1 x Power cable 1 x DisplayPort 1.4 cable - 1.8 m 1 x HDMI cable - 1.8 m 1 x Thunderbolt™ 4 passive cable - 1 m 1 x USB Type-A to USB Type-C Gen 2 cable - 1 m Quick setup guide Safety, Environmental and Regulatory Information Factory calibration report
